C7085-90921 Chapter 3 Installation and configuration 51
Installing the toner cartridges—for older
version HP Color LaserJet 4500 printers
Note
The following instructions are for older versions of the 4500 series
printers (see page 140 to determine which version of the printer you
have). See page 55 for instructions for installing toner cartridges in
newer version 4500 series and 4550 series printers.
1 Locate the toner cartridges packaged in the printer box. The printer
uses four different toner colors and has a different toner cartridge
for each color: K = black, M = magenta, C = cyan,
and Y = yellow.
2 Close all the doors and drawers on the printer. If the printer is not
already turned on, turn it on. Wait for the printer to warm up. When it
is ready, the control panel displays:
TONER POSITION
CYAN = MISSING.
Note
If the
INSTALL DRUM message appears, wait for the INSTALL TONER
CARTRIDGE message, then proceed with the following instructions.
3 Push the dark gray release button on the side of the printer ([1]) and
open the top cover ([2]).
1
2
3
