HP Color LaserJet CP5525 Series - Solid State Drive (SSD) Replacement

Solid State Drive
Remove and Replace --
Steps 5 through 12
If you have an N or DN model with a Solid State
Drive please use step 5 though 11 to remove and
replace the Drive with the same or new formatter
board. If you have an HX model, please skip to
step 13.
5
Solid State Drive procedures:
Twist the SSD retaining clip
6
Solid State Drive procedures:
Pull up on the SSD retaining clip
7
Solid State Drive procedures:
Pull the old SSD card out from the pin connector.
8
If replacing with new formatter board,
exchange it here.
NOTE: Do Not
replace both a new Formatter
board and new Solid State Drive at the same
time. Please replace drive first, reboot, and
then replace formatter.
