Bottom
Component Description
(1)
Battery lock and unlock latch Locks and unlocks the battery in the battery bay.
(2) Battery bay Holds the battery.
(3) Vent Enable airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(4)
Battery release latch Releases the battery.
(5) Speaker openings (4) Produce sound.
(6)
Service cover (select models only) Provides access to the memory module slots.
Bottom 15
