Display subcomponents (bezel, webcam, panel)
This section describes removing display subcomponents that do not require that you remove the entire
display assembly from the computer. You can remove the display bezel, webcam/microphone module, and
display panel while the display assembly is still attached to the computer.
To remove the remaining display subcomponents, you must remove the entire display assembly from the
computer. See
Display assembly on page 76 for more information about removing the display assembly in
its entirety.
Description Spare part number
Raw display panel for use in HP 14 and Compaq 14 models without a touch screen 760105-001
Raw display panel for use in HP 240 G3 models without a touch screen 766010-001
Raw display panel for use in HP 245 G3 models with a touch screen 778156-001
Raw display panel for use in HP 14 models, touch screen 760106-001
Raw display panel for use in Compaq 14 models, touch screen 757611-001
Display bezel for use with HP 14 models 757599-001
Display bezel for use with HP 240/246 G3 models 766009-001
Display bezel for use with HP 245 G3 models 766900-001
Display bezel for use with Compaq 14 models 757600-001
Webcam/microphone module, HD 757614-001
Webcam/microphone module, VGA 781623-001
Before removing display subcomponents while the display assembly is still attached to the computer, follow
these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 49).
To remove the display bezel, webcam/microphone module, and raw display panel:
1. Position the computer upright with the front toward you, and then open it.
2. Remove the two Mylar covers (1) and two Phillips PM2.0×3.0 screws (2) that secure the bezel to the
display.
3. Flex the inside of the top edge (3), the left and right sides (4), and the bottom edge (5) of the display
bezel until the bezel disengages from the display enclosure.
50 Chapter 4 Removal and replacement procedures
