3. Lift the rear edge of the cover (2), swing it forward, and remove the cover.
NOTE: The Bluetooth module compartment cover is included in the Plastics Kit, spare part
number 443905-001.
4. Remove the Bluetooth module (1) from the computer.
5. Disconnect the Bluetooth module cable (2) from the module.
6. Remove the Bluetooth module.
Reverse this procedure to reassemble and install the Bluetooth module.
Component replacement procedures 53
