10. Remove the six Torx T8M2.5×6.0 screws (1) that secure the display panel to the display
enclosure.
11. Remove the display panel (2).
12. Remove the four Phillips PM2.0×3.0 screws (1) that secure each display hinge to the display panel.
13. Remove the display hinges (2).
NOTE: The left and right display hinges are available using spare part number 447204-001.
Reverse this procedure to install the display assembly.
Top cover
Description Spare part number
Top cover (includes TouchPad, TouchPad cable, and fingerprint reader) 443921-001
Component replacement procedures 79
