Item Description Spare part

number

For use in Switzerland 486279-BG1

For use in Taiwan 486279-AB1

For use in Thailand 486279-281

For use in Turkey 486279-141

For use in the United Kingdom 486279-031

For use in the United States 486279-001

Memory modules (PC2-6400, 667-MHz, DDR2)

(4a) Primary memory module (located under keyboard)

(4b) Expansion memory module (located under memory/WLAN module compartment cover)

2048-MB 483194-001

1024-MB 483193-001

TouchPad assemblies (include the components listed below):

(5a) Fingerprint reader board and cable (included only in spare part kit 486277-001)

(5b) TouchPad board and cable

(5c) TouchPad board bracket

For use only with computer models equipped with a fingerprint reader (includes a fingerprint

reader board and cable)

486277-001

For use only with computer models not equipped with a fingerprint reader 486278-001

Plastics Kit (see Plastics Kit on page 28 for more Plastics Kit spare part information): 486292-001

(6a) PC Card slot bezel

(6b) Memory/WLAN module compartment cover

(6c) Hard drive bay cover

(6d) Bluetooth module compartment cover

Cable Kit (see Cable Kit on page 29 for more Cable Kit spare part information): 486281-001

(7a) Bluetooth module cable

(7b) Modem module cable (includes RJ-11 connector)

(7c) Microphone extension cable

System boards (include system board bracket, system board, and replacement thermal material):

(8a) System board bracket

(8b) System board

For use only with HP Compaq 6535b computer models equipped with both WLAN and WWAN

modules

488193-001

For use only with HP Compaq 6535b computer models equipped with a WLAN module and no

WWAN module

488194-001

24 Chapter 3 Illustrated parts catalog
