HP Compaq 6530b User Manual

Sequential part number listing
Spare part
number
Description
246959-001 Power cord for use in the United States
246959-011 Power cord for use in Australia
246959-021 Power cord for use in Europe, the Middle East, and Africa
246959-031 Power cord for use in the United Kingdom
246959-061 Power cord for use in Italy
246959-081 Power cord for use in Denmark
246959-201 Power cord for use in Brazil
246959-291 Power cord for use in Japan
246959-AD1 Power cord for use in South Korea
246959-AG1 Power cord for use in Switzerland
246959-BB1 Power cord for use in Israel
398393-002 Bluetooth module for use only on HP Compaq 6535b computer models in all countries and regions except in
Japan and Asia-Pacific countries and regions
NOTE: The Bluetooth module spare part kits do not include a Bluetooth module cable. The Bluetooth
module cable is included in the Cable Kit, spare part number 486281-001.
449137-001 RTC battery
450066-001 Bluetooth module for use only on HP Compaq 6535b computer models in Japan and Asia-Pacific countries
and regions
NOTE: The Bluetooth module spare part kits do not include a Bluetooth module cable. The Bluetooth
module cable is included in the Cable Kit, spare part number 486281-001.
463955-001 90-W PFC HP Smart AC Adapter for use in all countries and regions except India
463956-001 90-W non-PFC HP Smart AC Adapter for use only in India
483193-001 1024-MB memory module (PC2-6400, 667-MHz, DDR2)
483194-001 2048-MB memory module (PC2-6400, 667-MHz, DDR2)
483377-001 HSDPA EVDO WWAN module
486247-001 System board for use only with HP Compaq 6530b computer models equipped with both WLAN and WWAN
modules (includes replacement thermal material)
486248-001 System board for use only with HP Compaq 6530b computer models equipped with a WLAN module and no
WWAN module (includes replacement thermal material)
486249-001 USB/digital media board (includes cable)
486250-001 Audio board (includes cable)
486251-001 ExpressCard board (includes RTC battery)
486252-001 SIM connector board
486254-001 Intel Core2 Duo T8400 2.26-GHz processor for use only with HP Compaq 6530b computer models (3-MB L2
cache, 800-MHz FSB; includes replacement thermal material)
32 Chapter 3 Illustrated parts catalog

HP Compaq 6530b Specifications

General

HDD speed	7200 RPM
HDD interface	-
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	160 GB
Number of HDDs installed	1
Bus type	FSB
Stepping	R0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Motherboard southbridge	Intel ICH9M
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	25 W
Processor core voltage (AC)	1.00 - 1.250 V
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Operating system installed	Windows Vista Business
Operating system architecture	32-bit
Display diagonal	14.1 \
Display resolution	- pixels
Motherboard chipset	Intel GE45 Express
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows Vista
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	HD
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
AC adapter power	55 W
Number of battery cells	6
Product color	Black
Country of origin	China
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SLGFE
Processor ARK ID	37006
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	242.8 mm
Width	334.8 mm
Weight	2410 g
Height (front)	32.6 mm
