21. Remove the speakers (3) from the top cover.
22. Turn the computer right-side up, with the front toward you.
23. Open the computer as far as possible.
24. Disconnect the display panel cable (1) from the system board.
CAUTION: There is a ground loop off the display panel cable that is secured to the left hinge. Be
sure you do not pull or damage the cable.
25. Disconnect the camera and microphone module cables (2) from the system board, and then
remove the cables from the routing path (3).
26. Remove the wireless antenna cables (4) from the clips and routing channels built into the top cover.
10 Chapter 1 Removal and replacement procedures ENWW
