Phillips PM2.5×10.0 captive screw
Color Quantity Length Thread Head diameter
Silver 6 10.0 mm 2.5 mm 5.0 mm
Where used: 6 captive screws that secure the heat sink to the system board (screws are secured to the
heat sink by C-clips)
Phillips PM2.5×10.0 captive screw 111
