Item Description Spare part
number
For use in the United States 456587-001
(4) Speaker
457614-001
(5) Top cover (includes TouchPad board and cable, and TouchPad button board and cable)
457616-001
Plastics Kit (see Plastics Kit on page 18 for more Plastics Kit spare part information):
456614-001
(6a) ExpressCard slot bezel
(6b) WLAN module compartment cover (includes one captive screw, secured by a C-clip)
(6c) Memory module compartment cover (includes one captive screw, secured by a C-clip)
(6d) Hard drive bay cover (includes 2 captive screws, secured by C-clips)
TouchPad components
(7a)
TouchPad bracket (included in the Miscellaneous TouchPad Kit, which also includes the
TouchPad button board actuators, which are not illustrated)
457618-001
(7b) TouchPad board (includes cable)
457617-001
(8) TouchPad button board (includes cable)
456601-001
(9) ExpressCard assembly
456607-001
(10) System boards (include replacement thermal material)
Includes 128-MB of DDR2 graphics subsystem memory 456613-001
Includes 64-MB of DDR2 graphics subsystem memory 456612-001
Includes 128-MB of DDR1 graphics subsystem memory 456611-001
Includes 64-MB of DDR1 graphics subsystem memory 456610-001
(11) Battery connector board
457620-001
(12) Optical drive connector board
456805-001
(13) Fan
456604-001
(14) Heat sink (includes replacement thermal material)
456606-001
(15) Processors (includes replacement thermal material)
Intel Core 2 Duo processors:
●
T7700 2.40-GHz (4-MB L2 cache, 800-MHz FSB)
446894-001
●
T7500 2.20-GHz (4-MB L2 cache, 800-MHz FSB)
446893-001
●
T7300 2.00-GHz (4-MB L2 cache, 800-MHz FSB)
446892-001
●
T7100 1.80-GHz (2-MB L2 cache, 800-MHz FSB)
446891-001
Intel Celeron M processors:
●
550 2.00-GHz (1-MB L2 cache, 533-MHz FSB)
446888-001
●
540 1.86-GHz (1-MB L2 cache, 533-MHz FSB)
446889-001
(16) RTC battery
449137-001
(17) Modem module
441074-001
14 Chapter 3 Illustrated parts catalog
