HP Compaq 8100 Elite User Manual

7. Rotate up the external drive bay housing to access the memory module sockets on the system
board.
NOTE: Your computer may look different than the illustration shown below.
Figure 9 Rotating the Drive Cage Up
8. Locate the memory modules on the system board.
ENWW Installing Additional Memory 13

HP Compaq 8100 Elite Specifications

General

Chipset	Intel Q57 Express
Processor	Intel Core i5 or i7
Memory	Up to 16 GB DDR3 SDRAM
Storage	SATA hard drives up to 1 TB
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Form Factor	Small Form Factor (SFF), Convertible Minitower (CMT)
Audio	Integrated High Definition Audio with Realtek ALC261 codec
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, DisplayPort, VGA, serial, parallel, PS/2
Power Supply	240W (SFF), 320W (CMT)
