HP Compaq 8100 Elite User Manual

6. Use the Smart Cover FailSafe Key to remove the tamper-proof screw that secures the Smart Cover
Lock to the chassis.
NOTE: Your computer may look different than the illustration shown below.
Figure 1 Removing the Smart Cover Lock Screw
You can now remove the access panel. See Removing the Computer Access Panel on page 4.
To reattach the Smart Cover Lock, secure the lock in place with the tamper-proof screw.
ENWW Unlocking the Smart Cover Lock 3

HP Compaq 8100 Elite Specifications

General

Chipset	Intel Q57 Express
Processor	Intel Core i5 or i7
Memory	Up to 16 GB DDR3 SDRAM
Storage	SATA hard drives up to 1 TB
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Operating System	Windows 7 Professional
Form Factor	Small Form Factor (SFF), Convertible Minitower (CMT)
Audio	Integrated High Definition Audio with Realtek ALC261 codec
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, DisplayPort, VGA, serial, parallel, PS/2
Power Supply	240W (SFF), 320W (CMT)
