HP Compaq 8200 Elite User Manual

Side Components
Figure 1-3 Side Components
Table 1-2 Side Components
Component Component
1 HP 6-in-1 Media Card Reader 6 Tray-load optical drive
2 (2) USB 2.0 ports 7 Optical drive eject button
3 Microphone/line in jack 8 Brightness increase button
4 Headphone jack 9 Brightness decrease button
5 Optical drive activity LED 10 Hard drive activity LED
ENWW Side Components 3

HP Compaq 8200 Elite Specifications

General

Graphics	Intel HD Graphics 2000/3000 or optional discrete graphics
Network	Integrated Intel 82579LM Gigabit Ethernet
Chipset	Intel Q67 Express
Memory	Up to 32 GB DDR3 SDRAM
Storage	250GB, 320GB, 500GB, 1TB HDD or 128GB SSD
Optical Drive	DVD-ROM
Ports	USB 2.0, DisplayPort, VGA, serial, parallel, PS/2, audio in/out
Form Factor	Small Form Factor (SFF)
Audio	Integrated high-definition audio
Operating System	Windows 7
Power Supply	240W (SFF), 320W (MT)
Processor	Intel Core i3, i5, or i7 (2nd Gen)
