17.0-inch, WSXGA+WVA display specifications
Metric U.S.
Dimensions
Height 24.4 cm 9.6 in
Width 38.1 cm 15.0 in
Diagonal 43.2 cm 17.0 in
Number of colors Up to 16.8 million
Contrast ratio 200:1 (typical)
Brightness 180 nits (typical)
Pixel resolution
Pitch 0.172 × 0.172 mm
Format 1680 × 1050
Configuration RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 7.0 W
Viewing angle +/-60 horizontal, +40/-50° vertical (typical)
104 Chapter 6 Specifications
