HP Compaq 8710p Service Manual

Item Description Spare part number
For use in Slovakia 450472-231
For use in Slovenia 450472-BA1
For use in South Korea 450472-AD1
For use in Spain 450472-071
For use in Sweden and Finland 450472-B71
For use in Switzerland 450472-111
For use in Taiwan 450472-AB1
For use in Thailand 450472-281
For use in Turkey 450472-141
For use in the United Kingdom 450472-031
For use in the United States 450472-001
(5) TouchPads (include TouchPad cable)
For use with keyboards with a pointing stick, includes 3 pointing stick buttons and 3
TouchPad buttons
450597-001
For use with keyboards without a pointing stick, includes 2 TouchPad buttons 450596-001
(6) Top covers (include fingerprint reader board and cable )
For use with HP Compaq 8710w computer models 451379-001
For use with HP Compaq 8710p computer models 450595-001
(7) Graphics card fan/heat sink (includes replacement thermal material) 450594-001
(8) Heat sink assemblies (include replacement thermal material)
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468593-001
For use only with computer models equipped with processors with 2- or 4-MB L2 cache 450593-001
Plastics Kit (see
Plastics Kit on page 27 for more Plastics Kit spare part information): 450585-001
(9a) PC Card slot bezel
(9b) Memory module/WLAN module compartment cover (includes 3 captive screws, secured by C-clips)
Computer feet (not illustrated; 9 feet in 4 different sizes)
(9c) Hard drive cover (includes 2 captive screws, secured by C-clips)
(10) PC Card assembly 450584-001
(11) Intel Core 2 Duo processors (include replacement thermal material)
T9500 2.6-GHz processor (6-MB L2 cache, 800-MHz FSB) 463051-001
T9300 2.5-GHz processor (6-MB L2 cache, 800-MHz FSB) 463050-001
T8300 2.4-GHz processor (3-MB L2 cache, 800-MHz FSB) 463049-001
T8100 2.1-GHz processor (3-MB L2 cache, 800-MHz FSB) 463048-001
T7800 2.6-GHz processor (4-MB L2 cache, 800-MHz FSB) 458218-001
T7700 2.4-GHz processor (4-MB L2 cache, 800-MHz FSB) 450589-001
22 Chapter 3 Illustrated parts catalog

HP Compaq 8710p Specifications

General

Bus type	FSB
Stepping	C0
Tjunction	105 °C
Processor cache	6 MB
Processor cores	2
Processor model	T9300
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T9000 Series
Processor socket	LGA 3647 (Socket P)
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
Processor core voltage (AC)	1.062 - 1.150 V
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® PM965 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Display diagonal	17 \
Display resolution	1680 x 1050 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC
Power requirements	100 - 240V
Wireless technology	Wi-Fi
Graphics card family	NVIDIA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3x, IEEE 802.11g
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
Discrete graphics card model	NVIDIA Quadro NVS 320M
Maximum graphics card memory	0.5 GB
Discrete graphics card memory	0.25 GB
Audio system	AD1981HD
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows Vista Business
Number of battery cells	8
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	6
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor code	SLAYY
Processor ARK ID	33917
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	275 mm
Width	393 mm
Height	33 mm
Weight	3400 g
