HP Compaq 8710p Service Manual

Spare part
number
Description
450491-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive
450492-001 DVD/CD-RW Combo Drive
450493-001 100-GB, 7200-rpm hard drive
450494-001 120-GB, 5400-rpm hard drive
450495-001 160-GB, 5400-rpm hard drive
450496-001 80-GB, 5400-rpm hard drive
450497-001 80-GB, 7200-rpm hard drive
450498-001 Display inverter
450499-001 Label Kit
450500-001 Display bezel
450570-001 Display Bracket Kit (includes left and right display hinges)
450571-001 Display cable
450572-001 Display enclosure for use with WSXGA+ and WXGA+ display assemblies (includes 3 WLAN antenna
transceivers and cables)
450573-001 Display Rubber Kit (includes display bezel rubber screw covers)
450574-001 Display Screw Kit
450575-001 1024-MB memory module (PC-5300, 667-GHz, DDR2)
450576-001 2048-MB memory module (PC-5300, 667-GHz, DDR2)
450577-001 512-MB memory module (PC-5300, 667-GHz, DDR2)
450578-001 Microphone extension cable
450580-001 17.0-inch, WSXGA+ WVA AntiGlare display assembly (includes 3 WLAN antenna transceivers and
cables)
450581-001 17.0-inch, WSXGA+ WVA BrightView display assembly (includes 3 WLAN antenna transceivers and cables)
450582-001 17.0-inch, WUXGA+ WVA AntiGlare display assembly (includes 3 WLAN antenna transceivers and cables)
450583-001 17.0-inch, WXGA+ AntiGlare display assembly (includes 3 WLAN antenna transceivers and cables)
450584-001 PC Card assembly
450585-001 Plastics Kit (see
Plastics Kit on page 27 for more Plastics Kit spare part information)
446440-001 Intel Core 2 Duo T7100 1.8-GHz processor (2-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
450587-001 Intel Core 2 Duo T7300 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
450588-001 Intel Core 2 Duo T7500 2.2-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
450589-001 Intel Core 2 Duo T7700 2.4-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
450590-001 Rubber Kit (includes base enclosure rubber feet
36 Chapter 3 Illustrated parts catalog

HP Compaq 8710p Specifications

General

Bus type	FSB
Stepping	C0
Tjunction	105 °C
Processor cache	6 MB
Processor cores	2
Processor model	T9300
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T9000 Series
Processor socket	LGA 3647 (Socket P)
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
Processor core voltage (AC)	1.062 - 1.150 V
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® PM965 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Display diagonal	17 \
Display resolution	1680 x 1050 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC
Power requirements	100 - 240V
Wireless technology	Wi-Fi
Graphics card family	NVIDIA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3x, IEEE 802.11g
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
Discrete graphics card model	NVIDIA Quadro NVS 320M
Maximum graphics card memory	0.5 GB
Discrete graphics card memory	0.25 GB
Audio system	AD1981HD
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows Vista Business
Number of battery cells	8
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	6
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor code	SLAYY
Processor ARK ID	33917
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	275 mm
Width	393 mm
Height	33 mm
Weight	3400 g
