13. Flex the inside edges of the left and right sides (1) and the top and bottom sides (2) of the
display bezel until the bezel disengages from the display enclosure.
14. Remove the display bezel (3). The display bezel is available using spare part number
450500-001.
15. Remove the four mylar screw covers (1) from the left and right sides of the display enclosure.
16. Remove the four Torx T8M2.5×4.0 screws (2) that secure the display panel to the display
enclosure.
82 Chapter 4 Removal and replacement procedures
