HP Compaq 8710p - Computer Setup; Starting Computer Setup

4. Disconnect the fingerprint reader board cable from the system board.
5. Remove the three Torx T8M2.5×7.0 screws that secure the top cover to the computer.
6. Lift the rear edge of the top cover (1) until it rests at an angle.
7. Swing the rear edge of the top cover (2) up and forward until it disengages from the base
enclosure.
86 Chapter 4 Removal and replacement procedures
