Item Component Spare part number
(1) Display assembly (not spared)
NOTE: For display assembly spare part information, see
Display assembly subcomponents on page 20.
(2) Keyboard (includes keyboard cable):
NOTE: For a detailed list of keyboard spare parts, see
Sequential part number listing
on page 25.
698694-xx1
(3) Power button board (includes cable) 689686-001
(4) Top cover (includes TouchPad):
For use with Compaq models 689696-001
For use with blue HP models 689694-001
For use with black HP models 689695-001
(5) Speakers (includes left and right speakers and cable) 689693-001
(6) TouchPad button board (includes bracket and cables) 689688-001
(7) Fan/heat sink assembly (includes replacement thermal materials):
For use only with computer models equipped with an AMD processor 688281-001
For use only with computer models equipped with an Intel processor 685086-001
Hard Drive Hardware Kit, includes: 685089-001
(8a) Hard drive cable
(8b) Hard drive bracket
Plastics Kit, includes: 689689-001
(9a) Hard drive compartment cover (includes one captive screw, secured by a C-clip)
(9b) Memory module/wireless module compartment cover (includes one captive screw, secured by a C-clip)
NOTE: See
Plastics kit on page 23 for more plastics kit spare part information.
(10) Optical drive cable (includes cable bracket) 685084-001
(11) USB board (includes cable) 689687-001
(12) System board (includes replacement thermal materials):
For use only with models with an AMD A6-5200 processor
●
Models without Windows 8 730573-001
●
Models with Windows 8 Standard 730573-501
For use only with models with an AMD A4-5000 processor
●
Models without Windows 8 730574-001
●
Models with Windows 8 Standard 730574-501
For use only with models with an AMD E300 processor
●
Models without Windows 8 688279-001
●
Models with Windows 8 Standard 688279-501
16 Chapter 3 Illustrated parts catalog ENWW
