HP Compaq dc5700 User Manual

Unit Environment and Operating
Conditions
Microtower Small Form Factor
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is
operated within the specified operating range.
Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are subject to each other's re-
circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure,
and the same operating guidelines listed above will still apply.
Temperature Range Operating: 50° to 95° F (10° to 35° C)*
Non-operating: -22° to 140° F(-30° to 60° C)
Relative Humidity Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude (unpressurized) Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
* NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained
sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Microtower Small Form Factor
Power Supply 300-watt BTX power
supply – Passive PFC
115v/230v line switch
300-watt 80 PLUS* BTX
power supply – Active
PFC
240-watt BTX power
supply – Passive PFC
115v/230v line switch
240-watt 80 PLUS* BTX
power supply – Active
PFC
Operating Voltage Range 90 to 132VAC, or 180 to
264VAC
90 to 264VAC 90 to 132VAC, or 180 to
264VAC
90 to 264VAC
Rated Voltage Range 100 to 127VAC, or 200
to 240VAC
100 to 240VAC 100 to 127VAC, or 200
to 240VAC
100 to 240VAC
Rated Line Frequency 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency Range 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz
Rated Input Current 8A/4A 5A/2.5A 6A/3A 3.5A/1.75
Heat Dissipation Typical 315 btu/hr
(79 kg-cal/hr)
Maximum 1575 btu/hr
(397 kg-cal/hr)
Typical 270 btu/hr
(68 kg-cal/hr)
Maximum 1280 btu/hr
(322 kg-cal/hr)
Typical 315 btu/hr
(79 kg-cal/hr)
Maximum
1260 btu/hr
(317 kg-cal/hr)
Typical 270 btu/hr
(68 kg-cal/hr)
Maximum 1025 btu/hr
(258 kg-cal/hr)
Power Supply Fan Variable speed fan Variable speed fan Variable speed fan Variable speed fan
ENERGY STAR Compliant X X
FEMP Standby Power Compliant
(<2W in S5 – Power Off)**
X X X X
QuickSpecs
HP Compaq dc5700 Business PC
Technical Specifications
DA - 12545 Canada — Version 35 — February 12, 2009 Page 18

HP Compaq dc5700 Specifications

General

Tcase	73.3 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E4500
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E4000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Conroe
Processing Die size	111 mm²
Processor frequency	2.2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.85 - 1.5 V
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	167 M
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	2 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-ROM
Card reader integrated	Yes
Total storage capacity	160 GB
Platform	PC
Audio input	1
CD read speed	48 x
Security features	TPM1.2, Credential Manager, Smart Card Manager
Power requirements	90 – 264 V, 50/60 Hz
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Graphics card RAMDAC	400 MHz
USB 1.1 ports quantity	0
Audio formats supported	AAC, MP3, WAV, WMA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	-
Maximum graphics card memory	0.256 GB
Bundled software	Computer Setup Utility Diagnostics for Windows Microsoft Internet Explorer Live Update Subscription PDF Complete
Operating system installed	Windows XP Professional
USB 2.0 ports quantity	8
Modem speed	56 Kbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Power supply	400 W
Certification	FCC, CE, VCCI
Password protection type	BIOS
Processor code	SLA95
Processor ARK ID	30781
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	429.2 mm
Width	177.8 mm
Height	375.9 mm
Weight	10530 g
