HP Compaq dc5700 User Manual

Other Features Description
ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards
and peripherals in a low-power or powered-off state without affecting other
elements of the system.
SMBIOS Ver. 2.4 System Management BIOS, previously known as DMI BIOS, for system management
information
Wired for Management Support Intel-driven, industry-wide initiative to make Intel architecture-based PCs, servers and
mobile computers more inherently manageable right out of the box and over the network
Dual-State Power Button Power button acts as both an on/off button and suspend-to-sleep button
Serviceability Features of System
Dual Colour Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM Flash ROM CMOS Battery Holder for easy
Replacement
Flash Recovery with Video 5 Aux Power LED on System PCA Processor ZIF Socket for easy Upgrade
Over-Temp Warning on Screen
(Requires IM Agents)
Clear Password Jumper DIMM Connectors for easy Upgrade
Restore CD Clear CMOS Button NIC LEDs (integrated) (Green & Amber)
Serviceability Features of Chassis
Dual Colour Power and HD LED –
To Indicate Normal Operations
and Fault Conditions
Colour coordinated cables and
connectors
Tool-less Hood Removal
Front power switch System memory can be upgraded
upgraded on Microtower without
removing any internal components
Tool-less Hard Drive, CD & Diskette
Removal
Feature Description
ASF 2.0 support (Alert Standard Format) Industry-standard specification for network alerting and remote control in operating system-
absent environments
Towerable Product can be oriented as a tower (in addition to desktop orientation)
Drive Self Tests (DPS) Drive Protection System
A diagnostic hard drive self test. It scans critical physical components and every sector
of the hard drive for physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
QuickSpecs
HP Compaq dc5700 Business PC
Technical Specifications
DA - 12545 Canada — Version 35 — February 12, 2009 Page 20

HP Compaq dc5700 Specifications

General

Tcase	73.3 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E4500
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E4000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Conroe
Processing Die size	111 mm²
Processor frequency	2.2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.85 - 1.5 V
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	167 M
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	2 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-ROM
Card reader integrated	Yes
Total storage capacity	160 GB
Platform	PC
Audio input	1
CD read speed	48 x
Security features	TPM1.2, Credential Manager, Smart Card Manager
Power requirements	90 – 264 V, 50/60 Hz
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Graphics card RAMDAC	400 MHz
USB 1.1 ports quantity	0
Audio formats supported	AAC, MP3, WAV, WMA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	-
Maximum graphics card memory	0.256 GB
Bundled software	Computer Setup Utility Diagnostics for Windows Microsoft Internet Explorer Live Update Subscription PDF Complete
Operating system installed	Windows XP Professional
USB 2.0 ports quantity	8
Modem speed	56 Kbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Power supply	400 W
Certification	FCC, CE, VCCI
Password protection type	BIOS
Processor code	SLA95
Processor ARK ID	30781
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	429.2 mm
Width	177.8 mm
Height	375.9 mm
Weight	10530 g
