HP Compaq dc5700 User Manual

Value-added Software
(available for free
download from the Web
http://www.hp.com/
go/easydeploy )
HP Client Configuration Manager, Basic Edition HP Systems Software Manager
HP Client Manager for Altiris HP Client Catalog for Microsoft SMS
Altiris Out-of_Band Management Solution Verdiem Surveyor agent
HP SoftPaq Download Manager
Value-added Services and
Features
HP Stable Platform Program with Product Change
Notification
Factory Express Deployment and Lifecycle Services
Business-to-Business Portals TPM 1.2* Vista Bit-Locker Ready
HP Global Series Services Tool-less Serviceability
* TPM module disabled where use is restricted by law; for example, Russia.
Service and Support On-site Warranty and Service
Note 1
: This three-year (3-3-3), limited warranty and service offering
delivers three years of parts, labour and on-site repair. Response time is next business-day
Note 2
and
includes free telephone support
Note 3
24 x 7. Global coverage
Note 2
ensures that any product purchased
in one country and transferred to another non-restricted country will remain fully covered under the
original warranty and service offering. Some countries/regions do not offer one year onsite and labour.
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
NOTE 3 : Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
Microtower Small Form Factor
Chassis Dimensions
(H x W x D)
14.85”H x 6.95”W x 16.85”D 4.5”H x 15.5”W x 13.5”D
System weight* 23.44 lb (10.63 kg) 17.86 lb (8.10 kg)
System volume 1739 cu in 941.63 cu in
Shipping weight* 32.12 lb (14.57 kg) 26.70 lb (12.11 kg)
Shipping box dimensions
(H x W x D)
12.0 x 19.76 x 23.62 in 9.72 x 19.68 x 22.67 in
* Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.
Power Supply 300W power supply – passive PFC 240W power supply – passive PFC
80 PLUS Power Supply 300W 80 PLUS* power supply – active PFC 240W 80 PLUS* power supply – active PFC
* This alternate 80% efficient power supply is a requirement for ENERGY STAR compliance in conjunction with a select range of
processors and modules.
Ports
USB 2.0 8 (2 front, 6 rear) 8 (2 front, 6 rear)
Serial 1 standard with 2nd optional 1 standard with 2nd optional
Parallel 1 1
PS/2 1 keyboard, 1 mouse 1 keyboard, 1 mouse
QuickSpecs
HP Compaq dc5700 Business PC
Standard Features and Configurable Components
DA - 12545 Canada — Version 35 — February 12, 2009 Page 6

HP Compaq dc5700 Specifications

General

Tcase	73.3 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E4500
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E4000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Conroe
Processing Die size	111 mm²
Processor frequency	2.2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.85 - 1.5 V
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	167 M
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	2 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-ROM
Card reader integrated	Yes
Total storage capacity	160 GB
Platform	PC
Audio input	1
CD read speed	48 x
Security features	TPM1.2, Credential Manager, Smart Card Manager
Power requirements	90 – 264 V, 50/60 Hz
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Graphics card RAMDAC	400 MHz
USB 1.1 ports quantity	0
Audio formats supported	AAC, MP3, WAV, WMA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	-
Maximum graphics card memory	0.256 GB
Bundled software	Computer Setup Utility Diagnostics for Windows Microsoft Internet Explorer Live Update Subscription PDF Complete
Operating system installed	Windows XP Professional
USB 2.0 ports quantity	8
Modem speed	56 Kbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Power supply	400 W
Certification	FCC, CE, VCCI
Password protection type	BIOS
Processor code	SLA95
Processor ARK ID	30781
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	429.2 mm
Width	177.8 mm
Height	375.9 mm
Weight	10530 g
