HP Compaq dc5800 Specifications

Environmental
EnvironmentalEnvironmental
Environmental Operating temperature
Operating temperatureOperating temperature
Operating temperature 32° to 131°F (0° to 55° C)
Operating humidity
Operating humidityOperating humidity
Operating humidity 85% at 131° F (55° C)
Dimensions
DimensionsDimensions
Dimensions 4.4 x 2.2 x 0.08 in (11.2 x 5.5 x 2 cm)
Management capabilities
Management capabilitiesManagement capabilities
Management capabilities ACPI, WOL and DMI 2.0, PXE 2.1, WfM 2.0, Broadcom mgmt utility
HP Wireless A+G PCI
HP Wireless A+G PCIHP Wireless A+G PCI
HP Wireless A+G PCI Dimensions
DimensionsDimensions
Dimensions 4.99 x 2.54 x 0.71 in (126.8 x 64.4 x 18.0 mm)
Weight
WeightWeight
Weight 0.268 lb (65 g)
Controller
ControllerController
Controller
system interface
system interfacesystem interface
system interface
Atheros AR5414X chipset
PCI Spec 2.2
Network standard
Network standardNetwork standard
Network standard IEEE 802.11a/b/g
Frequency band
Frequency bandFrequency band
Frequency band 5.1500 to 5.8500 GHz
2.4000 to 2.4835 GHz
2.4465 to 2.4835 GHz (Europe, Middle East, Asia and Asia Pacific –
excluding Japan)
2.4000 to 2.4697 GHz (Japan)
Operating temperature
Operating temperatureOperating temperature
Operating temperature 32° to 140° F (0° to 60° C), operating
Storage temperature
Storage temperatureStorage temperature
Storage temperature -4° to 176° F (-20° to 80° C), non-operating
Humidity
HumidityHumidity
Humidity 10% to 85% non-condensing
Operating voltage
Operating voltageOperating voltage
Operating voltage 5V ± 5%
Power consumption
Power consumptionPower consumption
Power consumption Tx/Rx peak 560/250mA @ 3.3V (max.)
Output power
Output powerOutput power
Output power
(approximately)
15 dBM ±2dB
Receive sensitivity
Receive sensitivityReceive sensitivity
Receive sensitivity -90dBm at 11 Mbps (typical)
Data transfer rate
Data transfer rateData transfer rate
Data transfer rate Standard rates of 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 48, 54 and Super AG
Mode108-Mbps
Spreading
SpreadingSpreading
Spreading DSSS (Direct Sequence Spread Spectrum)
Security
SecuritySecurity
Security 64(40h) bit, 128(104h) bit, WPA, IEEE802.1X, AES-OCB, AES-CCM,
Microsoft PEAP,TKIP, WEP.
Antenna
AntennaAntenna
Antenna External 5dBi antenna
Throughput
ThroughputThroughput
Throughput 108 Mbps (only with Belkin 54G or
above router that supports 108 Mbps
speed)
200 ft (60.96 m) – Indoor
54 Mbps 200 ft (60.96 m) – Indoor
11 Mbps 200 ft (60.96 m) – Indoor
Certifications
CertificationsCertifications
Certifications Wi-Fi certified
Certifications for use by
Certifications for use byCertifications for use by
Certifications for use by
country
countrycountry
country
North America: United States, Canada
Europe: Austria, Belgium, Cyprus, Denmark, Finland, France, Germany,
Greece, Iceland, Ireland, Italy, Liechtenstein, Luxembourg, Netherlands,
Norway, Portugal, Spain, Sweden, Switzerland, United Kingdom
Australia
New Zealand
QuickSpecs
HP Compaq dc5800 Business PC
HP Compaq dc5800 Business PCHP Compaq dc5800 Business PC
HP Compaq dc5800 Business PC
Technical Specifications - Communications
DA - 12863 Canada — Version 24 — July 31, 2009 Page 25

HP Compaq dc5800 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
Audio system	High Definition Audio
Product type	PC
Drive bays	2 external 5.25 inch, 1 external 3.5 inch 2 internal 3.5 inch
Driver LAN	Microsoft Windows XP, Microsoft Windows Vista, FreeDos, Linux
LightScribe	Yes
Upgrade type	Windows Vista capable
Keyboard type	HP PS/2 Standard Keyboard
Audio included	Integrated High Definition audio with ADI1884 codec, microphone and headphone front ports, line-out and line-in rear ports, multistreaming capable, internal PC speaker
Diskette drive	Optional
Expansion slots	1 full-height PCI, 1 full-height PCI Express x16, 2 full-height PCI Express x1
Pointing device	HP PS/2 2-Button Optical Scroll Mouse
Power management	Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
Security features	Kensington Lock
Power requirements	Input voltage 90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz, active PFC optional (External 80% High Efficiency) Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Video card features	3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX9, DirectXVA, VMR9, GDI/GDI+; OpenGL 1.4.; Integrated VGA Controller; integrated 350 MHz RAMDAC; 400 MHz Controller Clock Speed; Overlay Planes: Single overlay support with 5x3 filtering; Maximum Color Depth: 32 bits/pixel; Multi-display Support: 2 displays can be supported via the motherboard's VGA connectors and SDVO/ADD2 option Intel Graphics Media Accelerator 3100 \u003C85 Hz @ 1920x1440, 75 Hz @ 2048x1536
Acoustic power emissions	IDLE (Fixed disk drive spinning): LWAd = 3.8 Bels; FIXED DISK (Random write): LWAd = 3.9 Bels
Non-operating relative humidity (non-condensing)	5 - 90 %
Bundled software	On some models only (not included with FreeDOS): HP ProtectTools Security Solutions, HP Backup and Recovery Manager, HP Insight Diagnostics (available via HP Backup and Recovery Manager), HP Software Agent, HP Total Care Advisor, HP Client Configuration Manager, HP Client Manager for Altiris, HP SoftPaq Download Manager, HP Client Catalog for Microsoft SMS, HP Systems Software Manager, Computer Setup Utility, Altiris Out-of-Band Management Solution, McAfee AntiVirus trial version, Roxio DigitalMedia Plus 7.2/Easy Media Creator 9 Optional preloaded software, only for certain configurations: PDF Complete, Computrace for Desktops, Verdiem Surveyor agent, InterVideo WinDVD 5.0, Microsoft Office 2007 Basic, Microsoft Office 2007 Professional, Microsoft Office 2007 Small Business, Microsoft Internet Explorer with AOL Toolbar
Applications supported	Windows Vista Premium ready
Operating system installed	Windows Vista Business
Compatible operating systems	FreeDOS
Optional operating system supplied	Windows XP Professional
I/O ports	Rear: 6 USB 2.0, 1 serial port, 1 optional serial port, 1 optional parallel port, 2 PS/2, 1 RJ-45, 1 VGA, audio in/out; Front: 2 USB 2.0, audio ports
Serial ports quantity	1
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Micro Tower
Country of origin	China
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card model	Intel® GMA 3100
Maximum graphics card memory	0.256 GB
On-board graphics card model	Not available
Power consumption (typical)	300 W
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	428 mm
Width	176 mm
Height	377 mm
Weight	8900 g
Package weight	4450 g
