Serviceability Features of System
Serviceability Features of SystemServiceability Features of System
Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM Flash ROM CMOS Battery Holder for easy
Replacement
Flash Recovery with Video 5 Aux Power LED on System PCA Processor ZIF Socket for easy
Upgrade
Over-Temp Warning on Screen
(Requires IM Agents)
Clear Password Jumper DIMM Connectors for easy Upgrade
Restore CD Clear CMOS Switch NIC LEDs (integrated) (Green &
Amber)
Serviceability Features of Chassis
Serviceability Features of ChassisServiceability Features of Chassis
Serviceability Features of Chassis
Dual Color Power and HD LED - To
Indicate Normal Operations and
Fault Conditions
Color coordinated cables and
connectors
Tool-less Hood Removal
(thumbscrews for Microtower, spring-
latch for Small Form Factor)
Front power switch System memory can be upgraded
upgraded on Microtower without
removing any internal components
Tool-less Hard Drive, CD & Diskette
Removal
Feature
FeatureFeature
Feature Description
DescriptionDescription
Description
ASF 2.0 support (Alert Standard Format) Industry-standard specification for network alerting and remote control in operating
system-absent environments
Towerable Product can be oriented as a tower (in addition to desktop orientation)
Drive Self Tests (DPS) Drive Protection System
A diagnostic hard drive self test. It scans critical physical components and every
sector of the hard drive for physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem
and needs to be replaced.
The system expands on the Self-Monitoring, Analysis, and Reporting Technology
(SMART), a continuously running systems diagnostic that alerts the user to certain
types of failures.
DPS Access through F10 Setup during Boot
SMART IV Technology*
(Self-Monitoring, Analysis and Reporting
Technology)
Allows hard drives to monitor their own health and to raise flags if imminent failures
were predicted
Predicts failures before they occur. Tracks fault prediction and failure indication
parameters such as re-allocated sector count, spin retry count, calibration retry
count
By avoiding actual hard drive failures, SMART hard drives act as "insurance"
against unplanned user downtime and potential data loss from hard drive failure
QuickSpecs
HP Compaq dc5850 Business PC
HP Compaq dc5850 Business PCHP Compaq dc5850 Business PC
HP Compaq dc5850 Business PC
Technical Specifications
DA - 12900 North America — Version 20 — July 31, 2009 Page 21

HP Compaq dc5850 Specifications

General

Processor cache	0.512 MB
Processor cores	2
Processor family	AMD Athlon X2
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	AMD
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	500 GB
External drive bays	2x 5.25\
Internal drive bays	2x 3.5\
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon 3100
Maximum graphics card memory	0.256 GB
Operating system installed	Windows Vista Business
Serial ports quantity	1
USB 2.0 ports quantity	8
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power supply	240 W
Chassis type	SFF
Product color	Black
Country of origin	China
Product type	PC
Motherboard chipset	AMD 780V

Weight and Dimensions

Depth	428 mm
Width	176.5 mm
Height	377.2 mm
Weight	10630 g
