HP Compaq dc7600 User Manual

Memory Configurations
Memory Configurations Memory Configurations
Memory Configurations –
One of the following
USDT
USDTUSDT
USDT SFF
SFFSFF
SFF CMT
CMTCMT
CMT
256-MB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (1 x 256) X X X
512-MB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (1 x 512) X X X
512-MB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (2 x 256) X X X
1-GB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (1 x 1GB) X X X
1-GB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (2 x 512) X X X
2-GB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (4 x 512) X X
3-GB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (3 x 1GB) X
4-GB DDR2 Synch Dram PC2-4200 (533-MHz) Non ECC (4 x 1GB) X X
256-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 256) X X X
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 512) X X X
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 256) X X X
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 512) X X X
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 512) X X
Expandability
ExpandabilityExpandability
Expandability USDT
USDTUSDT
USDT SFF
SFFSFF
SFF CMT
CMTCMT
CMT
PCI slots Optional with riser card:
1 full-height (4.2"), length (6.6")
2 low-profile (2.5"), length (6.6")
standard;
2 full-height (4.2"), length (6.875")
via optional riser card.
NOTE:
NOTE:NOTE:
NOTE: With riser card option,
express x1 and x16 slots are not
accessible.
2 full-height (4.2"), length (13.4")
standard;
(2 additional full-height slots
available via optional extender
card)
Max power per slot 25W 25W 75W
PCI Express x16 slot -- 1 low-profile (2.5"), length (6.6") 1 full-height (4.2"), length (10.5")
Max power per slot N/A 25W 75W
PCI Express x1 slot -- 1 low profile (2.5"), length (6.6") 1 full-height (4.2"), length (13.4")
Max power per slot N/A 10W 10W
External Bays 0 (use MultiBay) 2 4
3.5" N/A 1 1
5.25" N/A 1 (length 8.189") 3 (2 - length 8.189", 1 - length
5.71")
MultiBay 1 standard none none
IDE 1 IDE for Multibay I (12 mm) 1 IDE connector for opticals 1 IDE connectors for opticals
Internal 3.5" HDD Bays 1 1 2
Hard Drive Controller (PCI)
Supported
Serial ATA (support for SATA 1.5-Gb/s and 3.0-Gb/s hard drives)
Hard Drive Interfaces
Supported
1 Serial ATA interface 2 Serial ATA interfaces 2 Serial ATA interfaces
QuickSpecs
HP Compaq dc7600 Business PC
HP Compaq dc7600 Business PCHP Compaq dc7600 Business PC
HP Compaq dc7600 Business PC
Configurable Components
DA - 12253 North America — Version 36 — January 30, 2007 Page 12

HP Compaq dc7600 Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Memory Slots	4 DIMM slots
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Processor	Intel Pentium 4, Intel Celeron D, Intel Pentium D
Chipset	Intel 945G Express
Storage	SATA Hard Disk Drive
Graphics	Intel Graphics Media Accelerator 950
Optical Drive	DVD-ROM
Audio	Integrated High Definition Audio
Ports	USB 2.0, serial, parallel, audio in/out
Operating System	Windows XP Professional
Form Factor	Small Form Factor, Convertible Minitower
Processor Speed	Up to 3.8 GHz (Pentium 4) or 2.66 GHz (Core 2 Duo)
