HP Compaq dc7600 User Manual

Graphics
GraphicsGraphics
Graphics Integrated Intel Graphics Media Accelerator 950 X X X
DVI ADD2 SDVO single head Graphics Adapter for USDT X
DVI ADD2 SDVO single head Graphics Adapter (PCI-E x16) X X
ATI RADEON X300 SE PCI Express 128-MB DDR single head DVI with TV out X X
ATI RADEON X1300 256MB PCIe DVI w/TV X X
ATI RADEON X1600XT 256MB, full-height PCIe, dual DVI w/TV-out X
NVIDIA Quadro NVS 280 64-MB PCI dual head VGA X* X X
NVIDIA Quadro NVS 285 128-MB PCIe x16 dual head VGA X X
NVIDIA Quadro 55 NVS 64MB PCI low profile DVI w/TV-Out X*
NOTES
NOTESNOTES
NOTES :
*Requires optional PCI riser card.
** NVS 280 PCI can be selected as a second graphics card
when the NVIDIA Quadro NVS 285 is also installed, to provide
support for four monitors
Audio
AudioAudio
Audio Integrated High Definition audio with Realtek 2 channel ALC260 codec (all ports
are stereo)
X X X
Microphone and Headphone front ports X X X
Microphone rear port* X X X
Line-out and Line-In rear ports* X X X
Aux Input connection on system board X X X
Analog CD IN Support X**
Internal Speaker X X X
NOTE:
NOTE:NOTE:
NOTE: *Rear audio ports are re-taskable as Line-in, Line-out, or Microphone-in, with optional driver,
available only through download from HP support website. External speakers must be powered
externally.
** Available on USDT through MultiBay
Keyboard
KeyboardKeyboard
Keyboard –
One of the following
HP PS/2 Standard Keyboard X X X
HP USB Standard Keyboard X X X
HP USB Smartcard Keyboard X X X
Mouse
MouseMouse
Mouse –
One of the following
PS/2 2-Button Scroll Mouse X X X
PS/2 2-Button Optical Scroll Mouse X X X
USB 2-Button Optical Scroll Mouse X X X
USB 2-Button Scroll Mouse X X X
QuickSpecs
HP Compaq dc7600 Business PC
HP Compaq dc7600 Business PCHP Compaq dc7600 Business PC
HP Compaq dc7600 Business PC
Configurable Components
DA - 12253 North America — Version 36 — January 30, 2007 Page 15

HP Compaq dc7600 Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Memory Slots	4 DIMM slots
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Processor	Intel Pentium 4, Intel Celeron D, Intel Pentium D
Chipset	Intel 945G Express
Storage	SATA Hard Disk Drive
Graphics	Intel Graphics Media Accelerator 950
Optical Drive	DVD-ROM
Audio	Integrated High Definition Audio
Ports	USB 2.0, serial, parallel, audio in/out
Operating System	Windows XP Professional
Form Factor	Small Form Factor, Convertible Minitower
Processor Speed	Up to 3.8 GHz (Pentium 4) or 2.66 GHz (Core 2 Duo)
