NVIDIA Quadro NVS 285
NVIDIA Quadro NVS 285NVIDIA Quadro NVS 285
NVIDIA Quadro NVS 285
128-MB PCIe Dual Head
128-MB PCIe Dual Head128-MB PCIe Dual Head
128-MB PCIe Dual Head
Form Factor
Form FactorForm Factor
Form Factor Low profile, both ATX and low profile brackets included
Graphics Controller
Graphics ControllerGraphics Controller
Graphics Controller Integrated Quadro 285 2D graphics processor unit (GPU)
Bus Type
Bus TypeBus Type
Bus Type PCI-Express
Memory
MemoryMemory
Memory 128 MB DDR (64 MB local frame buffer plus 64 MB of system memory via
TurboCache)
Connector
ConnectorConnector
Connector DMS-59 to dual-DVI Y-cable or dual-VGA Y-cable
Dimensions
DimensionsDimensions
Dimensions Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Multi-monitor Support
Multi-monitor SupportMulti-monitor Support
Multi-monitor Support Dual analog or digital monitors
RAMDAC
RAMDACRAMDAC
RAMDAC Dual 350 MHz (integrated)
Maximum Pixel Clock
Maximum Pixel ClockMaximum Pixel Clock
Maximum Pixel Clock 350 MHz
Overlay Planes
Overlay PlanesOverlay Planes
Overlay Planes One 16-bit Video overlay plane
High-definition Video
High-definition VideoHigh-definition Video
High-definition Video
Processor
ProcessorProcessor
Processor (HDVP)
Full screen, full frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Available Graphics
Available GraphicsAvailable Graphics
Available Graphics
Drivers
DriversDrivers
Drivers
Microsoft Windows 2000 and Microsoft Windows XP (Provides full native
Dual View mode, Span or Big Desktop mode, and Clone mode)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://www.hp.com/country/us/en/support.html?pageDisplay=drivers
Analog Resolution
Analog ResolutionAnalog Resolution
Analog Resolution Maximum Colors Supported
Maximum Colors SupportedMaximum Colors Supported
Maximum Colors Supported Maximum Refresh Rate
Maximum Refresh RateMaximum Refresh Rate
Maximum Refresh Rate
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1600 x 1200
1920 x 1080
1920 x 1200
1920 x 1440
2048 x 1536
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
240 Hz
240 Hz
240 Hz
170 Hz
150 Hz
100 Hz
85 Hz
85 Hz
75 Hz
60 Hz
Digital Resolution
Digital ResolutionDigital Resolution
Digital Resolution Maximum Colors Supported
Maximum Colors SupportedMaximum Colors Supported
Maximum Colors Supported Maximum Refresh Rate
Maximum Refresh RateMaximum Refresh Rate
Maximum Refresh Rate
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1600 x 1200
1900 x 1200
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
75 Hz
75 Hz
75 Hz
60 Hz
60 Hz
60 Hz
60 Hz
QuickSpecs
HP Compaq dc7600 Business PC
HP Compaq dc7600 Business PCHP Compaq dc7600 Business PC
HP Compaq dc7600 Business PC
Technical Specifications - Graphics
DA - 12253 North America — Version 36 — January 30, 2007 Page 35

HP Compaq dc7600 Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Memory Slots	4 DIMM slots
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Processor	Intel Pentium 4, Intel Celeron D, Intel Pentium D
Chipset	Intel 945G Express
Storage	SATA Hard Disk Drive
Graphics	Intel Graphics Media Accelerator 950
Optical Drive	DVD-ROM
Audio	Integrated High Definition Audio
Ports	USB 2.0, serial, parallel, audio in/out
Operating System	Windows XP Professional
Form Factor	Small Form Factor, Convertible Minitower
Processor Speed	Up to 3.8 GHz (Pentium 4) or 2.66 GHz (Core 2 Duo)
