HP Compaq dc7600 User Manual

Energy Consumption
Energy ConsumptionEnergy Consumption
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation 88.5 W 84.5 W 89.5 W
Sleep* 4.2 W 4.2 W 4.5 W
Off 1.0 W 1.0 W 1.3 W
Heat Dissipation**
Heat Dissipation**Heat Dissipation**
Heat Dissipation**
115 VAC 230 VAC 100 VAC
Normal Operation 302 BTU/hr 299 BTU/hr 307 BTU/hr
Sleep* 14 BTU/hr 14 BTU/hr 15 BTU/hr
Off 3 BTU/hr 3 BTU/hr 14 BTU/hr
NOTES:
NOTES:NOTES:
NOTES:
* Energy Star low energy mode
** Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.
Declared Noise Emissions
Declared Noise EmissionsDeclared Noise Emissions
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(LWad, bels)
Sound Pressure
(LpAm, decibels)
Idle 4.0 29
Fixed Disk
(random writes)
4.0 30
Optical Drive
(sequential reads)
5.4 45
Longevity and Upgrading
Longevity and UpgradingLongevity and Upgrading
Longevity and Upgrading This product is designed to be upgraded, possibly extending its useful life by several years. Spare parts
are available throughout the warranty period and for up to 5 years after the end of production.
Upgradeability features contained in the product include:
Intel LGA775 processor socket
8 USB ports
2 multi-bay ports (optional)
4 empty PCI slots (2 standard, 2 low profile))
1 internal drive slots
4 memory slots
1 Serial Port (optional)
Batteries
BatteriesBatteries
Batteries This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000ppm by weight.
Battery size: CR2032 (coin cell)
Battery type: Lithium
QuickSpecs
HP Compaq dc7600 Business PC
HP Compaq dc7600 Business PCHP Compaq dc7600 Business PC
HP Compaq dc7600 Business PC
Technical Specifications - Environmental Data
DA - 12253 North America — Version 36 — January 30, 2007 Page 57

HP Compaq dc7600 Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Memory Slots	4 DIMM slots
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Processor	Intel Pentium 4, Intel Celeron D, Intel Pentium D
Chipset	Intel 945G Express
Storage	SATA Hard Disk Drive
Graphics	Intel Graphics Media Accelerator 950
Optical Drive	DVD-ROM
Audio	Integrated High Definition Audio
Ports	USB 2.0, serial, parallel, audio in/out
Operating System	Windows XP Professional
Form Factor	Small Form Factor, Convertible Minitower
Processor Speed	Up to 3.8 GHz (Pentium 4) or 2.66 GHz (Core 2 Duo)
