HP Compaq dc7800 Quickspecs

Other Features Description
ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards and peripherals in
a low-power or powered-off state without affecting other elements of the system.
SMBIOS Ver. 2.5 System Management BIOS, for system management information
Wired for Management
Support
Intel-driven, industry-wide initiative to make Intel architecture-based PCs, servers and mobile computers
more inherently manageable right out of the box and over the network
Dual-State Power Button Power button acts as both an on/off button and suspend-to-sleep button
Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM Flash ROM CMOS Battery Holder for easy
Replacement
Flash Recovery with Video
Configuration Record SW
5 Aux Power LED on System PCA Processor ZIF Socket for easy Upgrade
Over-Temp Warning on Screen
(Requires IM Agents)
Clear Password Jumper DIMM Connectors for easy Upgrade
HP Backup and Recovery Manager Clear CMOS Button NIC LEDs (integrated) (Green & Amber)
Serviceability Features of Chassis
Dual Color Power and HD LED – To
Indicate Normal Operations and
Fault Conditions
Color coordinated cables and
connectors
Tool-less Hood Removal
Front power switch System memory can be upgraded
without removing the system board or
any internal components
Tool-less Hard Drive, CD & Diskette
Removal
Green Pull Tabs, and Quick
Release Latches for easy
Identification
NOTE: Thumb screw release mechanism is used with the Ultra-slim Desktop chassis cover.
Additional Features Description
AMT 3.0 support (Active Management
Technology)
Select models offer new Intel vPro Technology utilizing AMT 3.0 for network alerting and
management of systems regardless of power state, as well as operating system-absent
environments.
Supports existing AMT 2.1 features plus:
QuickSpecs
HP Compaq dc7800 Business PC
Technical Specifications
DA - 12744 North America — Version 33 — October 29, 2008 Page 25

HP Compaq dc7800 Specifications

General

Tcase	73.3 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E4600
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E4000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Conroe
Processing Die size	111 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	167 M
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Total storage capacity	160 GB
Audio input	1
LightScribe	Yes
Networking features	Intel 82566DM Gigabit Network Connection
Graphics card RAMDAC	400 MHz
Storage drive controller	SATA 3, 0 Gb/s NCQ SMART VI
Discrete graphics card model	Intel® GMA 3100
Maximum graphics card memory	0.256 GB
Operating system installed	Windows Vista Business
USB 2.0 ports quantity	8
Chassis type	Mini Tower
Country of origin	China
Cable lock slot type	Kensington
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	365 W
Product type	PC
Processor code	SLA94
Processor ARK ID	32242
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	452 mm
Width	177 mm
Height	447 mm
Weight	11800 g
