EL-MF877-00 Page 10
Template Revision A
FIGURE 17: POWER SUPPLY 2: Capacitors (5) and small PCA to cut
FIGURE 18: POWER SUPPLY 3: Cover screw locations
FIGURE 19: POWER SUPPLY 3: Cover screw locations
