POWER SUPPLY PRINTED CIRCUIT ASSEMBLY
1 To remove the power supply (see Figure 4 below)
a) Remove all cables connected to all devices in the chassis.
b) Using a phillips screwdriver, remove the four screws that secure the power supply to
the chassis.
c) Slide the power supply toward the front of the computer, and then lift it out of the
chassis.
2 To remove the cover from the power supply (see Figures 5 & 6 below):
a) Using a phillips screwdriver, remove the six screws that secure the cover to the power
supply chassis.
b) Using dikes, cut the plastic cable clamp that secures the cables to the chassis.
c) Lift the cover off the power supply.
3 To remove the power supply PCA:
a) Cut the plastic cable clamp that secures the cables to the chassis
(see Figure 7 below).
b) Remove the four screws that secure the power supply PCA to the chassis
(see Figure 8 & 9 below).
c) Using diagonal cutters (dikes) cut all cables connected to the PCA (2 to switch, 2 to PC
inlet, 2 to power supply fan) (see Figure 10 below).
d) Remove the power supply PCA from the power supply chassis.
BATTERY
Locate the battery and battery holder on the system board. Depending on the type of
battery holder on the system board, follow the instructions below to remove the battery:
TYPE 1 BATTERY HOLDER (see Figure 11 below)
Lift the battery out of the holder.
TYPE 2 BATTERY HOLDER (see Figure 12 below)
To release the battery from its holder, squeeze the metal clamp that extends above one
edge of the battery. When the battery pops up, lift it out.
TYPE 3 BATTERY HOLDER (see Figure 13 below)
Pull back on the clip that holds the battery in place, and then remove the battery.
