Integrated Intel
WG82567V Gigabit
Network Connection
Connector
RJ-45
Controller
Intel WG82567V and ICH10R integrated MAC
Memory
Large 96kb receive and 8kb transmit on chip buffer
Data rates supported
10/100/1000 Mbps
Compliance
IEEE 802.3 compliant, 802.3x flow control
Bus architecture
PCI Express 1.1
Data transfer mode
Bus-master DMA
Hardware certifications
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark
for European Union
Power requirement
Aux 3.3V, 1.234 Watts in 1000base-T and 0.641 Watts in 100Base-T
Boot ROM support
Yes
Network transfer rate
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental
Operating temperature
32° to 120°F (0° to 48.89° C)
Operating humidity
85% at 120°F (48.89° C)
Dimensions
68Pin QFN (10mm x 10mm x 0.85mm)
Management capabilities
WOL, PXE, (WOL supported from S1, S3, S4 states only. Not supported
from S5 state).
Intel Gigabit CT Desktop
NIC
Connector
RJ-45
Controller
Intel WG82574L Gigabit Ethernet Controller
Memory
Integrated Dual 48K configurable transmit receive FIFO Buffers
Data rates supported
10/100/1000 Mbps
Compliance
IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control
Bus architecture
PCI-E 1.0a
Data path width
X1, 250 MB/s, Bi-directional interface
Data transfer mode
Bus-master DMA
Hardware certifications
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark
for European Union
Power requirement
Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Boot ROM support
Yes
Network transfer rate
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
QuickSpecs
HP Compaq dx7500 Business PC
Technical Specifications - Communications
DA - 13152 Worldwide QuickSpecs — Version 9 — 3/30/2009
Page 22
