Power Management
PCI Bus Power Management Interface Specification (PCI-PM) Revision 1.2,
Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in D3cold.
If the power management event (PME) feature is enabled in D3cold, a
modem can wake the system via WAKE# (WAKEN) or beacon. Meets PCI
Express 1.1 standard.
Upgradeability
Driver upgradeable for future enhancements
Video
ITU-T V.80 video ready interface
Other
TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel 16550a
UART-compatible interface
Optional ring wakeup signal
Operating Temperature
32° to 158° F (0° to 70° C)
Operating Humidity
20% to 90%, non-condensing
Power
Requires a 3.3-V auxiliary power rail on PCI express bus
Uses only one PCI express load (i.e., one grant/request pair), one shared
IRQ, one electrical load
Chipset
LSI SV92EX - Integrated PCI interface with 3.3-V tolerant buffers and CardBus
support
Dimensions
(L X H)
Complies with PCI express low profile specifications-6.7 x 2.3 in (17.0 x 5.8
cm) and supports high- and low-profile brackets
Connection
Single RJ-11 connector
Other Features
Digital line protection, call progress monitoring via on-board piezo device,
support for high profile and low profile brackets, PnP ID support
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950 (TUV,
NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO, DEMKO,
SEMKO, CE mark
EMC
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Other
The SV92EX device is packaged in a 32-pin micro leadless chip carrier
(MLCC). The SV92EX is fully compliant with the PCI Express revision 1.1
specification. WHQL approved; ASPM compliant.
QuickSpecs
HP Compaq dx7500 Business PC
Technical Specifications - Communications
DA - 13152 Worldwide QuickSpecs — Version 9 — 3/30/2009
Page 26
