1920x1200 60-R
NOTE: 60-R denotes reduced blanking timings are used. Not all monitors support reduced blanking
timing.
NVIDIA GeForce
GT130 768MB
PCIe x16
Graphics Card
Bus type PCI Express (x16 lanes)
Input/Output
connectors
DVI-I (DVI port supports dual-link and HDCP)
VGA and HDMI
Board display
options
Supports two displays through any combination of two of the three output ports.
Board configuration Specification Description
Graphics Chip NVIDIA GeForce GT130
Core clock 550 MHz
Memory clock 500 MHz
Frame buffer 768MB DDR2
Maximum vertical
refresh rate
85 Hz
Display support Integrated 400 MHz RAMDAC
Display max
resolution
2048 x 1536 (analog), 2560x1600 (digital)
NVIDIA GeForce GT130 768MB PCIe x16 Graphics Controller display resolutions and refresh rates
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
Resolution Maximum Refresh Rate (Hz)
Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R *
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A 60 **
* Max HDMI resolution is 1080p
** Only supported when using a dual-link DVI connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
connections
QuickSpecs
HP Compaq dx7500 Business PC
Technical Specifications - Graphics
DA - 13152 Worldwide QuickSpecs — Version 9 — 3/30/2009 Page 29
