HP 2-Button Scroll Mouse
(PS/2)
Scroll Wheel 8 mm
Maximum Rotation Speed 30 mm/s
Switch Type Light force micro-switch
Switch Life 1 million operations
Mechanical Life Minimum 200,000 revolutions
Environmental Operating Temperature 50° to 122° F (10° to 50° C)
Non-operating
Temperature
–22° to 140° F (–30° to 60° C)
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
Electrical Operating Voltage + 5VDC ± 10%
Power Consumption 15mA
System Consumption PS/2 mini-din connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing
device
PC98 Functionally compliant
Mechanical Resolution 400 ± 20% DPI
Tracking Speed 10 in/s maximum
Acceleration 100 in/s
Switch Actuation 85 g nominal peak force
Switch Life 1,000,000 operations (using Hasco modified
tester)
Cable Length 2 m
PC98-99 Mechanically compliant
Regulatory Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C-Tick
QuickSpecs
HP Compaq dx7500 Business PC
Technical Specifications - Input Devices
DA - 13152 Worldwide QuickSpecs — Version 9 — 3/30/2009 Page 38
