HP Compaq LA2405wg User Manual

Rear Components
Figure 3-2 Rear Components
Component Function
1 AC Power Connector Connects the AC power cord to the monitor.
2 DisplayPort Connects the DisplayPort cable (not included) to the monitor.
3 DVI Connects the DVI-D cable to the monitor.
4 VGA Connects the VGA cable to the monitor.
5 USB Upstream
Connector
Connects the USB hub cable to the monitor's USB hub
connector and to a host USB port/hub.
6 USB Downstream
Connectors (2)
Connects optional USB devices to the monitor.
6 Chapter 3 Setting Up the Monitor ENWW

HP Compaq LA2405wg Specifications

General

Screen Size	24 inches
Resolution	1920 x 1200
Aspect Ratio	16:10
Panel Type	TN
Brightness	250 cd/m²
Contrast Ratio	1000:1
Response Time	5 ms
Dynamic Contrast Ratio	3000:1
Height Adjustment	Yes
Pivot	Yes
Swivel	Yes
Tilt	Yes
Inputs	VGA, DVI
Viewing Angles	160° horizontal, 160° vertical
Dimensions	558 x 382 x 245 mm (with stand)
