2 Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Attaching the Monitor Base
1. Lift the base from the monitor box and set it on a flat surface such as a table top.
2. Using both hands, lift the monitor from its box, position the pedestal over the base, and press
down firmly to lock it in place. Be sure the base is securely locked in place and adjust the tilt
angle to the desired position.
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-
uniformity of color or disorientation of the liquid crystals. If this occurs the screen will not recover to its
normal condition.
Figure 2-1 Attaching the Monitor Base
NOTE: To remove the base, press inward on the tab in the center of the underside of the base and
pull the base from the pedestal.
ENWW Attaching the Monitor Base 3
