Components
Notebook Tour 1–3
2 Wireless lights
†
(2) On: An integrated wireless device,
such as a wireless local area network
(LAN) device and/or a Bluetooth®
device, is turned on.
3
Caps lock light On: Caps lock is on.
4 Num lock light On: Num lock is on.
5 Volume mute light On: Computer sound is turned off.
6
Battery light Amber: A battery pack is charging.
Green: A battery pack is close to full
charge capacity.
Blinking amber: A battery pack that is
the only available power source has
reached a low-battery condition. When
the battery reaches a
critical
low-battery condition, the battery light
begins blinking rapidly.
Off: If the computer is plugged into an
external power source, the light is
turned off when all batteries in the
computer are fully charged. If the
computer is not plugged into an
external power source, the light stays
off until the battery reaches a
low-battery condition.
7
Drive light Blinking green: The hard drive or
optical drive is being accessed.
Amber: The hard drive is parked.
*The 2 power lights display the same information. The light on the power
button is visible only when the computer is open. The power light on the
front of the computer is visible whether the computer is open or closed.
†
The 2 wireless lights display the same information. The light on the
wireless button is visible only when the computer is open. The wireless light
on the front of the computer is visible whether the computer is open or
closed.
Component Description
