Item Component Spare part number
(1) 14.0-in, high definition (HD), light-emitting diode (LED), BrightView display assembly (includes microphone
and wireless antenna transceivers and cables):
For use only with computer models equipped with an AMD processor:
Equipped with webcam 663603-001
Not equipped with webcam 645986-001
For use only with computer models equipped with an Intel processor, equipped with
webcam
645984-001
NOTE: For more display assembly spare part information, see
Display assembly subcomponents on page 24.
(2) Keyboard (includes keyboard cable):
For use with all computer models:
For use in Canada 646125-121
For use in Latin America 646125-161
For use in the United States 646125-001
For use only with computer models equipped with an Intel processor:
For use in Brazil 646125-201
For use in India 646125-D61
For use in South Korea 646125-AD1
For use in Taiwan 646125-AB1
For use in Thailand 646125-281
(3) Top cover (includes TouchPad and TouchPad cable):
For use only with computer models equipped with an AMD processor 645962-001
For use only with computer models equipped with an Intel processor 645963-001
(4) Power button board (includes cable) 646171-001
(5) TouchPad button board (includes bracket and cable) 646172-001
Cable Kit, includes: 645968-001
(6a) TouchPad cable
(6b) Optical drive connector cable
(6c) Hard drive connector cable
NOTE: See
Cable Kit on page 23 for more Cable Kit spare part information.
(7) USB board (includes cable) 645972-001
(8) Power connector cable 646173-001
Plastics Kit, includes: 645981-001
(9a) Hard drive compartment cover (includes one captive screw, secured by a C-clip)
(9b) Memory module/wireless module compartment cover (includes one captive screw, secured by a C-clip)
NOTE: See
Plastics Kit on page 28 for more Plastics Kit spare part information.
Computer major components 19
