Keyboard
NOTE: The keyboard spare part kit includes a keyboard cable.
Description Spare part number Description Spare part number
For use with all computer models: For use in Latin America 646125-161
For use in Canada 646125-121 For use in the United States 646125-001
For use only with computer models equipped with an
Intel processor:
For use in South Korea 646125-AD1
For use in Brazil 646125-201 For use in Taiwan 646125-AB1
For use in India 646125-D61 For use in Thailand 646125-281
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Remove the memory module/wireless module compartment cover (see
WLAN module
on page 42).
6. Remove the hard drive compartment cover (see
Hard drive on page 46).
Remove the keyboard:
1. Remove the Phillips PM2.5×5.0 screw that secures the keyboard to the computer.
2. Rest and secure the computer on its left side.
Component replacement procedures 51
