7–4 Maintenance and Service Guide

Screw listing

Phillips PM2.5×5.0 screw

Where used: 5 screws that secure the switch cover to the computer

Color Quantity Length Thread Head diameter

Black 5 5.0 mm 2.5 mm 5.0 mm
