5–78 Maintenance and Service Guide
Removal and Replacement Procedures
5.21 USB Board
✎
This section applies to Compaq Presario V4000 models. Refer
to steps 11 through 18 in Section 5.18, “System Board,” for
instructions for removing the USB board and frame on
HP Pavilion dv4000 models.
1. Prepare the computer for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. Switch cover (Section 5.12)
c. Keyboard (Section 5.13)
d. Display assembly (Section 5.14)
e. Top cover (HP Pavilion dv4000 models, Section 5.15)
f. Base enclosure (Compaq Presario V4000 models,
Section 5.16)
g. System board (Section 5.18)
2. Position the top cover with the left side toward you.
USB Board Spare Part Number Information
USB board (includes frame) 384625-001
