Docking and Undocking the Tablet PC
Tablet PC TC1000 Docking Station Reference Guide 2–3
Docking the Tablet PC
Power to the tablet PC can be on or off when docking or
undocking, and the tablet PC can be docked with or without
the optional keyboard. The screen protector must be resting
on the tablet PC screen, and not folded back, to prevent
blocking the docking connector.
To dock the tablet PC:
1. Align the docking alignment slots on the tablet PC with the
alignment brackets on the docking stand.
2. Tilt the top of the tablet PC toward the docking stand.
Docking the tablet PC
✎
Be sure not to press the tablet PC into the docking stand without
supporting the back of the docking stand. Failure to support the
docking stand could result in an insufficient connection between
the tablet PC and the docking stand.
289315-001.book Page 3 Friday, July 26, 2002 9:59 AM
