6–18 Maintenance and Service Guide
Removal and Replacement Procedures
6.9 Keyboard Cover
1. Prepare the tablet PC for disassembly (Section 6.3).
2. Position the tablet PC with the front toward you.
3. Remove the two T8M2.0×9.0 screws 1 and the two
T8M2.0×18.0 screws 2 that secure the keyboard cover to the
tablet PC.
Removing the Keyboard Cover Screws
Keyboard Cover Spare Part Number Information
Keyboard cover 383519-001
To Next Page
