6–38 Maintenance and Service Guide
Removal and Replacement Procedures
6.17 Display Assembly
1. Prepare the tablet PC for disassembly (Section 6.3).
2. Remove the keyboard cover (Section 6.9).
3. Remove the keyboard (Section 6.10).
4. Close the tablet PC.
5. Turn the tablet PC upside down with the rear panel
toward you.
Display Assembly Spare Part Number Information
12.1-inch, XGA, TFT display assembly (includes wireless
antenna boards and cables)
383548-001
Display Hinge Kit (not illustrated) 383531-001
To Next Page
