6–42 Maintenance and Service Guide
Removal and Replacement Procedures
14. Rotate the display clockwise 90 degrees 1.
15. Remove the two T8M2.0×18.0 screws 2 and the
two PM2.0×7.5 screws 3 that secure the display assembly to
the tablet PC.
Removing the Display Screws
