HP Compaq tc4200

C–2 Maintenance and Service Guide
Screw Listing
Phillips M2.0×5.0 Screw Locations
Table C-1
Phillips PM2.0×5.0 Screw
Color Qty. Length Thread
Head
Width
Black 6 5.0 mm 2.0 mm 4.5 mm
Where used:
1 Two screws that secure the hard drive cover to the tablet PC (documented in
Section 6.4)
2 Two screws that secure the memory module compartment drive cover to the
tablet PC (documented in Section 6.7)
mm
