HP Compaq tc4200

C–10 Maintenance and Service Guide
Screw Listing
Torx T8M2.0×9.0 Screw Locations
Table C-6
Torx T8M2.0×9.0 Screw
Color Qty. Length Thread
Head
Width
Black 12 9.0 mm 2.0 mm 4.5 mm
Where used:
1 Three screws that secure the keyboard to the tablet PC (documented in
Section 6.9)
2 Two screws that secure the keyboard cover to the tablet PC (documented in
Section 6.9)
3 Seven screws that secure the top cover to the tablet PC (documented in
Section 6.18)
mm
