HP Compaq tc4200

C–16 Maintenance and Service Guide
Screw Listing
Torx T8M2.0×5.0 Screw Locations
Table C-9
Torx T8M2.0×5.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 8 5.0 mm 2.0 mm 4.5 mm
Where used:
1 Two screws that secure the speaker to the tablet PC (documented in
Section 6.20)
2 One screw that secures the infrared board to the tablet PC (documented in
Section 6.21)
mm
